Micro SD Card Carrier

September 25, 2021 · admin 3D Printing object

This object is a simple micro SD card carrier having the same size as an SD card. It was designed to put a micro SD card into a SD card case that contains sleeves.

My small personal photo album is back online. The main gallery of this photo album is Maquettes. It contains a few pictures of the models, my father, Paul-Émile Théroux built using match sticks. I'll publish all the models he made in the next months. One thing no one can deny, my father was tremendously patient. You can access the photo album using this link, photos.ctheroux.com .

Raspberry PI Case 1B+/2/3

September 11, 2021 · admin 3D Printing object

This is a minimalist case for a Raspberry Pi 1B+, 2 or 3. Why another case when there are so many out there? This one has the smallest footprint. Most important, it has a 7 mm clearance between the bottom of the case and the Raspberry Pi. 2 mounting holes are provided on the bottom. With that clearance, the screws won't touch the Raspberry Pi even if using M5 screws. This case is designed to be mounted on 2020 aluminum extrusions.

DIN Rail Prototyping Stand V02

August 28, 2021 · admin 3D Printing object

This is a stand when used with some DIN Rails makes a useful electronic prototyping rig. You will be able to move your prototypes easily with it. Feet are also provided to tilt a bit the stand (15 degrees). You will find on Thingiverse or Printables many accessories. Search for DIN Rail.

Waveshare Pi Pico Quad Expander Base Plate

August 14, 2021 · admin 3D Printing object

This is a baseplate for the Waveshare Pi Pico Quad Expander. You will need 4 or more tiny screws to mount it. An infill of 15% is recommended. Support is not needed.

Coaster Set

July 25, 2021 · admin 3D Printing object

This is a coaster set. This design limits the contact surface between the recipient and the coaster. The deep design prevents the condensation waters from touching the recipient.

Create a Linux Program Launcher Icon

July 5, 2021 · admin Ubuntu Linux GitHub

Two tools are now available in the GitHub repository located at <https://github.com/ctheroux/LinuxUtilities-Users> to create a program launcher for most Linux systems.

TronXY X5SA Z Cable Chain Holder

June 12, 2021 · admin 3D Printing object

This is a replacement of the stock Z Axis Cable Chain Holder of the TronXY X5SA. The straight design is inappropriate because of the nuts on the extrusion side. I have design one that works perfectly.

DIN Rail Prototyping Stand

May 23, 2021 · admin 3D Printing object

This is a stand when used with some DIN Rails makes a useful electronic prototyping rig. You will be able to move your prototypes easily with it. In the picture, the bottom part of the stand is 20 mm higher than the height in the supplied STL file. It makes the stand more practical. You will find on Thingiverse or Printables many accessories. Search for DIN Rail.

4 Digits Nixie Tube Clock Stand

April 25, 2021 · admin 3D Printing object

This is a 15 mm in height stand for a 4 Digits Nixie Tube Clock. This clock is available on AliExpress. The base of the clock is 40 mm x 111 mm.
