2.36mm Wire Holder
May 9, 2020
· admin
3D Printing
object
This is a small wire holder. It is designed for 2.36 mm wires in diameter including its insulation.
Mini Solder Spool
May 2, 2020
· admin
3D Printing
object
Soldering electronic components using a large solder spool of 454 grams or so is quite inconvenient even if it is mounted on a solder spool holder. I prefer to wind a small amount of it on a smaller spool. This is what this mini solder spool is for. It can hold about 75 grams of solder wire.
Pull Handle
April 25, 2020
· admin
3D Printing
object
This is a simple pull handle. A #10 flat head screw is recommended to fasten it.
TRENDnet TK-409K KVM Holder for Ikea Ivar
April 18, 2020
· admin
3D Printing
object
This is a holder for a TRENDnet TK-409K KVM. The holder is hanged on a unit side of the Ikea Ivar shelving system. The TRENDnet TK-409K is a 4 ports Keyboard/Video/Mouse switch.
Parametric Bumper Feet
April 10, 2020
· admin
3D Printing
object
This is a simple OpenSCAD project that generates bumper feet for various objects. It was specifically designed to replace the lost bumper feet of a Falcon Print Trimmer. Printing it using TPU is the best way to go. A sample is included. To create a custom one:
Nuvistor Display Stand
April 4, 2020
· admin
3D Printing
object
This is a display stand for an old electronic part: the Nuvistor which is a type of vacuum tube. It was announced by RCA in 1959.
ESP8266 Motion Sensor Case
March 28, 2020
· admin
3D Printing
object
This is a case for a motion sensor based on the ESP8266 and the HC-SR501, a PIR (motion) sensor.
4 inches x 0.7 inches Label Holder
March 21, 2020
· admin
3D Printing
object
This is a paper tag holder made out of 4 inches (10.1 cm) x 3 inches (7.6 cm) index cards. They fit an edge of about 1/4 (6.25 mm) of an inch wide. A piece of size 4 inches (10.1 cm) x 0.7 (1.75 cm) inch out of the index card fits well.
Hanging Buckets for Power Supplies
March 14, 2020
· admin
3D Printing
object
This kit of objects is two hanging buckets set for a cheap bench power supply. One bucket is 100 mm deep. The other is 50 mm deep. They are held together by two arms that you must glue to the buckets. The buckets are 84 mm apart.
Ikea Bror Caster Holder
March 7, 2020
· admin
3D Printing
object
This object lets you install casters to a Bror workbench. It is designed for 1-7/8" (48.5 mm) x 2-9/16" (65.5 mm) casters. The holes for the bolts are 2-1/8" (54 mm) x 1" (25 mm) apart. The bolts I used are 1/4" (6.25 mm) in diameter, 1/2" (12.5 mm) long.
